Description
Gray overall. A yellow and a white band are stenciled just forward of the suspension lug. There is a red band around the nose.
A steel nose piece is held by three grub screws to a steel sealing plate. The plate is welded to a tubular-steel body by a continuous circumferential weld. A burster tube threads into the sealing plate and the joint is made airtight by a lead washer. A tail cone is welded to the after end of the body.
Four steel fins are welded to the tail cone and are braced by two sets of tubular struts.
This bomb designed to contain gas.
Hazardous Components
400-450 rubber bungs (1 inch long by 1 inch diameter) impregnated with phosphorus dissolved in carbon disulphide. The high explosive charge in the nose and central burster tube is picric acid.
Incendiary filling (37 lbs, 16.8 kg). Picric acid (5.5 lbs, 2.5 kg).
